Measurement of Alminum (Al) Alloy Sample

SEA1200VX performs high sensitivity measurements of Aluminum alloys resulting in superior "limit of detection" and excellent repeatability.

Measurement of cadmium (Cd) in alminum (Al) alloy

Excellent linearity of the calibration curve for aluminum alloys was created at optimal measurement conditions resulting in a detection lower limit of 3.6ppm Cd at a measuring time of 300 seconds.

-
-
(Al Alloy sample made by Sumitomo Metal Technology)

Measurement of lead (Pb) in alminum (Al) alloy

A detection lower limit of Pb 4.2ppm is achieved due to excellent linearity of the calibration curve at optimal measurement conditions.

-
-
(Al Alloy sample made by Sumitomo Metal Technology)

Measurement of chromium (Cr) in alminum (Al) alloy

The detection lower limit of Cr in Al alloy is 18ppm at 300 seconds.

-
-
(Al Alloy sample made by Sumitomo Metal Technology)

Repeatability at 300 seconds measurement

Repeatability tests at 300 seconds show superior Cd CV value of 1%, Pb CV value of 0.2%, and Cr CV value of 1.7%.

Measurment Conditions
Voltage: 50kV (Cd, Pb), 15kV (Cr)
Current: 1000µA (Cd), 273µA (Pb), 353µA (Cr)
Collimator: φ8mm
Filter: for Cd, Pb & Cr
Time: 300 sec.

StandardSample
Al Alloy GAL5 made by Sumitomo Metal Technology

  Cd Pb Cr
Ave. (ppm) 165 1180 138
Readings 20
STDEV (ppm) 2.1 2.1 2.3
CV% 1.2 0.2 1.7
Results (ppm) 178 1204 140
